Eyemax / EX-SDI IR Bullet / 2MP / COB IRx8 / 2.8~12mm Auto Focus / ICR / AC 24V/DC 12V / Smart Mount II

1/2.9 inch SONY CMOS (IMX-222 • IMX-322) • Extended Serial Digital Interface • 0 Lux at IR On (IR LED 08pcs) • Upgraded Waterproof Housing (IP 68 rating) • DNR (Digital Noise Reduction) • Digital WDR (Wide Dynamic Range) • Day & Night (ICR Option) • Easy Installation • ICR V/F lens • DC Auto IRIS V/F Lens • DC Auto IRIS & TDN V/F Lens • Auto Focus Motorized 2.8~12mm Vari-focal Lens

SKU: UIR-M2344V-B Categories: ,
Brand:

$ 279.00

Quantity
Compare

Description

SPECIFICATIONS

Resolution 1080P, 720P
Sensor 1/2.9 inch SONY CMOS (IMX-222 / IM × 322)
Total Pixels 2000(H) × 1241(V) = 2,482,000
Effective Pixels 1944(H) × 1092(V) = 2,122,648
Scanning System PROGRESSIVE
S/N (Y signal) More than 52 dB (AGC Off)
Video Output SMPTE292M (HD-SDI) / (CVBS: 1.0Vp-p (75ohm) : Option) (TVI : OPTION)
Min. Illumination IR PRODUCT : 0 Lux at IR On
1 Lux at F1.2 / 0.1 Lux (B/W)
White Balance AUTO / AUTO EXT / PRESET / MANUAL
Electronic shutter speed AUTO / MANUAL (1/30sec ~ 1/30,000sec) / Flicker
SENS_UP OFF / × 2 / × 4 / × 8 / × 16 / × 32
DNR OFF / LOW / MIDDLE / HIGH
BACKLIGHT OFF / WDR / BLC / HLC
ACE OFF / LOW / MIDDLE / HIGH
Day & Night AUTO (Day <–> Night TIME Change) , COLOR , B/W, EXTERN
PRIVACY / FLIP / FREEZE OFF / ON
MOTION / DEFOG OFF / SET
D.ZOOM x1.0 ~ × 16.0
Language ENG, CHN, CHN(S), JPN, KOR
Sharpness / Brightness ADJUSTABLE (Sharpness : 0 ~ 10 STEP / Brightness : 0 ~ 20 STEP )
COMM. RS-485(PELCO-D)
Temperature/Humidity Operating (14°F ~ 122°F(−10°C ~ 50°C)/ 30% ~ 80% RH) / Storage (−4°F ~ 140°F(−20°C ~ 60°C) / 20% ~ 90% RH)
Power AC24V / DC12V Dual Power
signal Transmission The distant difference is occurred according to cable option and other circumstances.
(based on 5C-HFBT : HD-SDI (200M) / EX-SDI (400M))
